Top-slide degree rotation scale
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Above and below: the very high quality of
construction is clearly evident in these photographs of the
power-cross-feed gearing
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Unusually long (and hence slow-wearing) top slide
bronze nut
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Sheet metal strip was used to protect the feed
screw from swarf and dirt
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Micrometer carriage stop--with an unusually small
dial
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
As on all screwcutting Carstens lathes backgear
(for slow speeds) was by epicyclic gearing built into the largest diameter
of the headstock pulley
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Twin V-belts brought the drive up from the
stand-mounted speed-change countershaft
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
The front of the spindle was shaped for the direct
fitting of draw-in collets
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
10-speed (with backgear) multi-V-belt countershaft
unit using a Z-section (10 mm wide) belt. Final drive was by twin A-section
(13 mm) belts
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
